series 705

DOUBLE-ACTING BLOCK CYLINDERS

705

DOUBLE-ACTING BLOCK CYLINDERS

These compact double-acting cylinders available with a wide range of forces and strokes are particularly suitable in applications requiring repeated high-speed cycles.

In all 10 models available the piston is in hardened steel, while the nitrited body guarantees good protection against corrosion, thus minimizing wear.



WARNING:

For pressures over 150 bar the cylinder must be equipped with back rest.

FORCES

from 43 to 175 kN

STROKES

from 25 to 50 mm.

PRESSURE

Maximum 350 BAR
