J415

STANDARD LINE | 4 STAGE

J415

4 STAGE HYDRAULIC JACK

- 1° stage > 76.500 kg.

- 2° stage > 45.000 kg.

- 3° stage > 27.500 kg.

- 4° stage > 14.500 kg.

working pressure: 10 bar - 143 p.s.i.

min. height: 175 mm.

max cylinder stroke: 305 mm.

air-inlet: G1/4

eng-16-25_50_100_prolunghe-in-dotazione

PT 16-25 (5.033.0005)
PL50 (5.066.0029)
PL100 (5.066.0030)

dimensions: 135x35x30 cm.

net weight: 115 kg.

of the same series
portable Standard Line
all the series
by numbers of stage

STANDARD LINE

CONSTANT PROGRESS

An exclusive design implemented in a range of 19 compact, functional models is the best response to today’s constant progress in vehicle construction. The built-in safety valves prevent accidental overloads and prevent the load from dropping in the event of a pneumatic pressure failure.
